Huixian Xinda Textile Machinery Parts Co., Ltd. provides textile hardware Sulzer Projectile Loom Copper Joint 927224300. The domestic substitute is composed of four parts, the assembly is in a right angle shape, and the shape parameters are: the total length is 28.7mm, the width is 25mm (the total width is 25.8mm, including the protruding position of the big nut), the thickness of the middle main body copper bend is 9.4mm, and the total thickness (the thickness of the big nut) is 12mm.
As shown in the above figure, the bottom left corner is the finished product of a combination of four components, while the other four are the disassembled components. The upper left corner is a copper elbow, with a single weight of 12 grams. Its silk thread outer diameter is 9.5mm, its inner hole diameter is 6.2mm, and its length is 8.3mm; The other end is an internal thread with a diameter of 7mm and a spherical hollow bead (diameter 5.5mm, thickness 4mm, inner hole 4.3mm) inside.
The size of the hexagonal large nut for Sulzer accessories - copper joints: the total length is 17.2mm (including threads), the main length of the nut is 9.3mm, the distance between the six edges is 12mm, the diameter of the inner thread is 9mm, and the weight of a single large nut is 7g. The parameters of the copper joint small nut: the total length is 11mm, the thread is M8, the length of the thread pattern is 6mm, the diameter of the inner hole is 4.4mm, the distance between the hexagonal faces is 8mm, the thickness of the hexagonal faces is 3.4mm, the outer diameter at the smooth neck is 6.5mm, and the weight of a single small nut is approximately 0.07g.
The total weight of this copper joint assembly is approximately 20 grams, packaged in self sealing bags of 50 pieces per bag, with a minimum order quantity of 10 pieces and a delivery time of approximately 8-10 days. The above are domestic replacement parts. Swiss Sulzer projectile loom accessories have certain differences in appearance due to different production processes between domestic substitute parts and original machine accessories, but they do not affect normal use.
If you need to purchase P7100 gripper shuttle connectors, PU copper connectors, TW11 Sulzer accessories, and Sulzer Projectile accessories 927224300 products, please contact Mr. Yang from "Xinda Textile Machinery Accessories" for consultation. We sincerely welcome domestic and foreign customers to negotiate and cooperate!
